RED FLUSH COMPLETE PUSHBUTTON DIA22 SPRING RETURN 1NC UNMARKED

Name: RED FLUSH COMPLETE PUSHBUTTON DIA22 SPRING RETURN 1NC UNMARKED
Brand: SCHNEIDER ELECTRIC
Price: 55494.45 IDR
Availability: InStock

Pilih Kontak

1NC

1NO

Pilih Warna

Biru

Hijau

Hitam

Kuning

Merah

Kode Produk

XB5AA42

Nama Produk

RED FLUSH COMPLETE PUSHBUTTON DIA22 SPRING RETURN 1NC UNMARKED

Keterangan

XB5 (MODULAR TYPE PLASTIK) SCHNEIDER ELECTRIC - XB5AA42

Brand

Schneider Electric

Type

Push Button 22mm

Warna (Cap/Operator or Lens Colour)

Merah

Kontak (Contacts Type and Composition)

1NC

Ketersediaan Stok

${item.title}
Stok Tersedia

Stok Tidak Tersedia
Tersedia di ${resources.length} lokasi Cabang - Lihat Semua
Tidak ada data cabang

Download the XB5AA42 red flush complete pushbutton Ø22 spring return 1NC unmarked, product datasheet, by clicking here!

Technical Characteristic:

Product Code : XB5AA42
Brand : Schneider Electric
Product Name : RED FLUSH COMPLETE PUSHBUTTON DIA22 SPRING RETURN 1NC UNMARKED
Description : XB5 (MODULAR TYPE PLASTIK) SCHNEIDER ELECTRIC - XB5AA42
Range of product : Harmony XB5
Product or component type : Push-button
Bezel material : Plastic, Dark grey plastic
Head type : Standard
Fixing collar material : Plastic
Mounting diameter : 22.5 mm
Cap/operator or lens colour : Red
Shape of signaling unit head : Round
Type of operator : Spring return
Operator profile : Red flush, unmarked
Contacts type and composition : 1 NC
Height : 42 mm
Width : 30 mm
Depth : 52 mm
Net weight of Schneider Electric Push Button 22 mm XB5AA42 : 0.037 kg

Schneider Electric Push Button

A push button is a push-button switch that functions to connect or disconnect the electric current. Push buttons work by pressing unlock; that is, when the button is pressed, the switch will work, and when the button is released, the switch will return to normal. Push buttons are often used in various applications, such as starting and ending machine work in industry, emergency buttons or automatic door switches, activating emergency alarms, induction motor control systems, and game systems for user interaction.

You can shop safely at ListrikKita.com because all the items we sell are guaranteed 100% original, officially guaranteed, and can be accompanied by a letter of authenticity of the goods. For more information or to make a large purchase, please contact our sales or marketing team by clicking here. Happy shopping!

This Harmony XB5, modular red push button operates with a spring return / impulse mechanism and uses screw clamp terminals. This push button provides a simple and robust control to machines and processes. It is easily installed into standard 22mm diameter cut-outs and connected with simple screw-clamp connections. Its schematic is clearly distinguishable visually at a distance thanks to clear colors and markings, minimizing errors during initial wiring and later maintenance operations. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 / IP67 / IP69 / IP69K, making it ideal for operation in harsh environments. Its plastic bezel makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation.

Specification

Spring-return	TRUE
Colour front ring	Black
Type of electric connection	Screw connection
Hole diameter	22.5 Millimetre
Material front ring	Plastic
Switching function latching	FALSE
Type of button	Flat
Construction type lens	Round
Number of contacts as normally open contact	0
Colour button	Red
Number of contacts as change-over contact	0
With front ring	TRUE
Suitable for illumination	FALSE
Degree of protection (IP)	IP66
Number of contacts as normally closed contact	1
Number of command positions	1
Transparent	FALSE
Degree of protection (NEMA)	4X
