PANEL MOUNTED ANGLED SOCKET IP67 125A 2P+PE 200-250V BIRU

Download the 81290 PANEL MOUNTED ANGLED SOCKET IP67 125A 2P+PE 200-250V BIRU product datasheet, by clicking  here!

Technical Characteristic:

• Product Code : 81290
• Brand : Schneider Electric
• Product Name : PANEL MOUNTED ANGLED SOCKET IP67 125A 2P+PE 200-250V BIRU
• Description : PANEL MOUNTED ANGLED SOCKET SCHNEIDER ELECTRIC - 81290
• Range : PratiKa
• Product or component type : Socket
• Device short name : PratiKa socket
• Plug, socket category : Low voltage
• Poles description : 2P + E
• Network type : AC
• Outlet standard : Industrial
• Mounting mode : Panel-mounted
• Plug, socket, control station shape : Angled
• [In] rated current : 125 A
• [Ue] rated operational voltage : 200...250 V
• Network frequency : 50/60 Hz
• Ground lug clockwise position : 6 h
• Net weight : 1.022 kg
• Base dimension : 110 x 114 mm
• Height : 114 mm
• Width : 129 mm
• Depth : 166 mm
• Colour : Grey (RAL 7035)
• Voltage colour : Blue

Schneider Electric Mureva PK

The Mureva range of industrial sockets and sockets is designed to meet all needs and environments: tertiary sector, industry, building sites, workshops and agricultural sector, as well as indoor and outdoor applications. The result of our experience and know-how, the complete range is available for 16 A, 32 A, 63 A and 125 A with IP44 and IP67 protection levels in traveler, panel and wall versions.

You can shop safely at ListrikKita.com because all the items we sell are guaranteed 100% original, officially guaranteed, and can be accompanied by a letter of authenticity of the goods. For more information or to make a large purchase, please contact our sales or marketing team by clicking here. Happy shopping!

Specification

IEC-amperage	125 Ampere
Connection system	Screwed terminal
Flange size vertical	114 Millimetre
Flange size horizontal	110 Millimetre
Insert direction	Angled
Material	Plastic
Rated frequency	50…60 Hertz
Rated voltage	200…250 Volt
Voltage according to EN 60309-2	230 V (50+60 Hz) blue
Identification colour	Blue
Drill hole distance horizontal	90 Millimetre
RAL-number	7035
Number of poles	3
Degree of protection (IP)	IP67
Clock hour position	6 Hour
Military model	FALSE
