MCCB (Susol dan Metasol) LS ELECTRIC dapat digunakan untuk perlindungan pada aplikasi Power Distribusi, Motor dan Peralatan Kontrol dengan Breaking Capacity tinggi dan ukuran yang sederhana.
Susol MCCB LS ELECTRIC memastikan pengoperasian yang aman dan nyaman dengan bermacam Trip Unit. Selain itu, memiliki desain sederhana dan kokoh yang menggambarkan kekuatan produk Industri.
Metasol MCCB LS ELECTRIC, memenuhi standar internasional, memiliki ukuran yang sama dengan Metasol ELCB (Earth Leakage Circuit Breaker) LS ELECTRIC. Selain dapat digunakan untuk aplikasi di Industri dapat juga digunakan untuk aplikasi di Perumahan dan Gedung Komersial.
Metasol ELCB (Earth Leakage Circuit Breaker) LS ELECTRIC memberikan perlindungan pada: Beban lebih, Arus singkat dan Arus bocor sesuai dengan standard IEC-60947-2.
1. Susol MCCB LS ELECTRIC
- Tipe E-series
Spesifikasi :- Aplikasi = Distribusi Power
- Kapasitas Arus: 16~1600A
- Breaking capacity (Icu): 36~150kA @ 380/415VAC
- Service breaking capacity (Ics): 100%
- Trip Unit = Adjustable Thermal, Fixed Magnetic trip unit (FMU)
- Ir (A) = 0.8 - 1x In
- Standar IEC 60947-2
- Tipe TD100 dan TD160 (FMU)
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 16-160 A
- Breaking Capacity = 50-150kA (at 380/415 VAC)
- Ics = 100% x Icu
- Trip Unit = Adjustable Thermal, Fixed Magnetic trip unit (FMU)
- Ir (A) = 0.8 - 1x In
- Ii (A) = Fixed 400A dan 10x In
- Tipe TS100, TS160, dan TS250 (FMU)
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 40-250 A
- Breaking Capacity = 50-150kA (at 380/415 VAC)
- Ics = 100% x Icu
- Trip Unit = Adjustable Thermal, Fixed Magnetic trip unit (FMU)
- Ir (A) = 0.8 - 1x In
- Ii (A) = 10x In
- Tipe TS400, TS630 dan TS800 (FMU)
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 300-800 A
- Breaking Capacity = 65-150kA (at 380/415 VAC)
- Ics = 100% x Icu
- Trip Unit = Adjustable Thermal, Fixed Magnetic trip unit (FMU)
- Ir (A) = 0.8 - 1x In
- Ii (A) = 10x In
- Tipe TS160 dan TS250 (ATU)
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 125-250 A
- Breaking Capacity = 50-150kA (at 380/415 VAC)
- Ics = 100% x Icu
- Trip Unit = Adjustable Thermal, adjustable Magnetic trip unit (ATU)
- Ir (A) = 0.8 - 1x In
- Ii (A) = 5 - 10x In
- Tipe TS400, TS630 dan TS800 (Atu)
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 300-800 A
- Breaking Capacity = 65-150kA (at 380/415 VAC)
- Ics = 100% x Icu
- Trip Unit = Adjustable Thermal, adjustable Magnetic trip unit (ATU)
- Ir (A) = 0.8 - 1x In
- Ii (A) = 5 - 10x In
- Tipe TS100, TS160, dan TS250 (ETS)
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 40-250 A
- Breaking Capacity = 50-150kA (at 380/415 VAC)
- Ics = 100% x Icu
- Trip Unit = Electronic Trip Unit tipe standar (ETS)
- Ir (A) = 0.4 - 1x In
- Isd (A) = 1.5 - 10x Ir
- Ii (A) = fixed 11x In
- Tipe TS400, TS630, dan TS800 (ETS)
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 160-800 A
- Breaking Capacity = 65-150kA (at 380/415 VAC)
- Ics = 100% x Icu
- Trip Unit = Electronic Trip Unit tipe standar (ETS)
- Ir (A) = 0.4 - 1x In
- Isd (A) = 1.5 - 10x Ir
- Ii (A) = fixed 11x In
- Aplikasi Proteksi Motor (MTU)
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Proteksi Motor
- Kapasitas Arus = 1.6 - 630 A
- Breaking Capacity = 50-150kA (at 380/415 VAC)
- Ics = 100% x Icu ˙Trip Unit = Adjustable Magnetic trip unit (MTU)
- Ii (A) = 6 - 12x In
2. Metasol MCCB LS ELECTRIC
- 30AF
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 3-30 A
- Breaking Capacity = 14-18kA (at 380 VAC) / 10-14kA (at 415 VAC)
- Ics = 100% x Icu
- Trip Unit = Fixed Thermal, fixed Magnetic trip units (FTU)
- 50AF
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 15-50A
- Breaking Capacity = 18-50kA (at 380 VAC) / 14-50kA (at 415 VAC)
- Ics = 100% x Icu
- Trip Unit = Fixed Thermal, fixed Magnetic trip units (FTU)
- 60AF
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 15-60A
- Breaking Capacity = 18-22kA (at 380 VAC) / 14-18kA (at 415 VAC)
- Ics = 100% x Icu
- Trip Unit = Fixed Thermal, fixed Magnetic trip units (FTU)
- 100AF
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 15-100 A
- Breaking Capacity = 22kA (at 380 VAC) / 18kA (at 415 VAC)
- Ics = 100% x Icu
- Trip Unit = Fixed Thermal, fixed Magnetic trip units (FTU)
- 125AF
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 15-125 A
- Breaking Capacity = 42-60kA (at 380 VAC) /37-60kA (at 415 VAC)
- Ics = 100% x Icu (tipe S dan H)
- Trip Unit = Fixed Thermal, fixed Magnetic trip units (FTU)
- 250AF
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 100-250 A
- Breaking Capacity = 30-60kA (at 380 VAC) / 26--60kA (at 415 VAC)
- Ics = 100% x Icu (tipe N / S / H)
- Trip Unit = Fixed Thermal, fixed Magnetic trip units (FTU)
- 400AF
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 250-400 A
- Breaking Capacity = 42-100kA (at 380 VAC) / 37-85kA (at 415 VAC)
- Ics = 100% x Icu (tipe N / S / H)
- Trip Unit = Fixed Thermal, fixed Magnetic trip units (FTU)
- 800AF
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 500-800 A
- Breaking Capacity = 45-100kA (at 380 VAC) / 37-85kA (at 415 VAC)
- Ics = 100% x Icu (tipe N dan S)
- Trip Unit = Fixed Thermal, fixed Magnetic trip units (FTU)
- 1000AF dan 1200AF
Spesifikasi :- Standard = IEC60947-2
- Aplikasi = Distribusi Power
- Kapasitas Arus = 1000-1200 A
- Breaking Capacity = 65-85kA (at 380 VAC) / 65-85kA (at 415 VAC)
- Ics = 50% x Icu
- Trip Unit = Fixed Thermal, fixed Magnetic trip units (FTU)
