LIFASA is a company consolidated in the electrical market thanks its constant evolution. In fact, LIFASA policy of investment in innovation and technology has positioned LIFASA as one of the pioneers in promoting the quality of electrical power capacitors.
Currently, Lifasa have a wide range of low and high voltage equipment, from equipment for small installations to the most complex ones with electronic control, thyristors and harmonic protection filters.
- Three – Phase Cylindrical Capacitor LIFASA
Technical Characteristics :
• Rated Voltage : 230-690V
• Frequency : 50Hz
• Dielectric : Polypropylene
• Isolation Level : 3/6kV rms
• Dielectric Losses : < 0.2W/kvar
• Total Losses : < 0.4W/kvar
• Discharge resistors : Fitted
• Max. Overvoltage : 1.1 Un
• Max. Overcurrent : 1.8 ln
• Power tolerance : -5 / + 10%
• Climatic Range : -40 / +55oC
• Connection : Terminals Block
• Protection : IP20
IP54
• Standards : IEC 60831, EN 60831, UL 810 - Three – Phase Prismatic Capacitor LIFASA
Technical Characteristics :
• Rated Voltage : 230-690V(MFB), 1000V(FML)
• Frequency : 50Hz – 60Hz
• Dielectric : Polypropylene
• Discharge resistors : Fitted
• Dielectric Losses : ≤ 0.2W/kvar
• Total Losses : ≤ 0.5W/kvar
• Max. Overvoltages : 1.1 Un (8h/day)
• Max. Overcurrent : 1.3 ln
• Insulation Level : 3/15kV
• Power tolerance : -5 / + 10%
• Climatic Range : -40 / +55oC
• Connection : M6(MFB), M10(FML)
• Protection Degree : IP41
• Colour : RAL7035
• Standards : IEC 60831, EN 60831 - Detuned Reactor for Harmonic Protection Filters LIFASA
Technical Characteristics :
• Rated Voltages Of The Main : 230/440V
• Frequency : 50Hz – 60Hz
• Rated Voltages Of The Capacitors : 260/460V
• Filter Type : Low Tuning
• Resonance Frequency : 189Hz (7%)
• Inductance Tolerance : ± 3%
• Maximum Harmonics Overload : 0.35ln
• Construction : INA : Aluminium
INR : Copper
• Thermal Protection : By Thermostat
• Insulation Level : 4kV
• Connection : INA : Aluminium Bus Bar
INR : Terminal Block
• Degree of Protection : INA : IP00 / INR : IP20
• Category of Temperature : Clase F (155 oC)
• Installation : Indoor
• Standards : IEC 60289, EN 60289
IEC 6007 6-6, EN 6007 6-6 - Contactor for Capacitor LIFASA
Technical Characteristics :
• Coil Voltage : 230v
• Coil Voltage Tolerance : 0,85 to 1,1Un
• Frequency : 50/60Hz
• Insulating Rating : 690V
• Operating Temperature : -25o to 55oC
• Compliance With : IEC 60947 – 4 ULCSA
