A Cubicle Panel is an electrical device or equipment that functions as a controller, connector, breaker and protector as well as dividing electrical power from an electric power source. Panel Cubicle is a general term that includes switching equipment and its combination with control, measurement, protection and regulatory equipment. The equipment is assembled and interconnected with fixtures, enclosures and supports.
The LBS SM6 (load break switch) cubicle functions as a breaker or connector for the 20kv electricity supply. The connecting contact is equipped with an arc damper so that it can be operated in different situations, it can be installed on the incoming or outgoing cable of a distribution substation or switch substation. In general, LBS cubicles are equipped with a ground switch inside the LBS tube or separately outside the tube which works interconnectively with LBS diagram symbols and LBS images.
Schneider Electric has been developing protection, monitoring, and control solutions specifically dedicated to medium-voltage networks for over 40 years. SM6 MV has been specially designed based on that extensive experience. It also incorporates some very new solutions, providing the best service and operator safety.
Schneider Electric's SM6 MV enabled with our EcoStuxure takes substation monitoring to the next level.
The SM6 panel cubicle Schneider Electric is fully compatible with :
- PowerMeter unit of measurement.
- Easergy P3 relay and multifunction protection Easergy Sepam relay : protection, measurement, and diagnosis.
- VIP protection : self-powered relay for protection
Therefore, Schneider Electric's SM6 Panel Cubicle can be easily integrated into any monitoring and control system with local and remote indication and operation.
MV SM6 features : Schneider Electric's SM6 switchgear, enabled with our EcoStuxure, takes substation monitoring to the next level. Identify poor electrical connection quality faster with thermal monitoring, extend the life of your equipment with environmental monitoring systems, or collect data on circuit breaker performance. Get all the information at your fingertips for unmatched visibility to keep your equipment operational and reduce maintenance costs.
Schneider Electric MV SM6 Advantages:
- Round-the-clock connectivity makes it possible to get real-time data to make effective decisions.
- Reduced downtime and more optimal maintenance costs
- Reduce risks to staff and equipment with electrical burst detection systems and close operation.
Listrikkita.com sells various kinds of LBS SM6 Cubicle Panels such as: IM MANUAL, QM MANUAL, QM MOTORIZE, IM MOTORIZE, IMLA MANUAL, CM, GAMLA, GAM, and END PLATE, etc.
Immediately get the LBS SM6 Cubicle Panel only at Listrikkita.com
