VOLTAGE CONTROL RELAY RM17U RANGE 20-80VAC SCHNEIDER ELECTRIC

Name: VOLTAGE CONTROL RELAY RM17U RANGE 20-80VAC SCHNEIDER ELECTRIC
Brand: SCHNEIDER ELECTRIC
Price: 830371.58 IDR
Availability: InStock

Pilih Suplai daya

20-240V AC/DC 50/60Hz

Self Powered 12 VDC

Self Powered 20-80V AC/DC

Self Powered 65-260V AC/DC

Pilih Output

1 C/O relay 5A

2 C/O relay 5A

Kode Produk

RM17UBE16

Nama Produk

VOLTAGE CONTROL RELAY RM17U RANGE 20-80VAC SCHNEIDER ELECTRIC

Keterangan

KONTROL TEGANGAN - RM17UBE16

Brand

Schneider Electric

Control Circuit Voltage

20-80VAC

Tipe

Control Relay

Ketersediaan Stok

${item.title}
Stok Tersedia

Stok Tidak Tersedia
Tersedia di ${resources.length} lokasi Cabang - Lihat Semua
Tidak ada data cabang

Kode Produk : RM17UBE16 Brand : Schneider Electric Nama Produk : VOLTAGE CONTROL RELAY RM17U RANGE 20-80VAC SCHNEIDER ELECTRIC Keterangan : KONTROL TEGANGAN - RM17UBE16

This Harmony RM17-UB relay allows monitoring of voltage control in single phase networks. This modular multi function single phase voltage control relay is ideal for monitoring of electrical values in industrial and building control panels. It applies to a wide type of industrial automation applications such as hoisting, packaging, lifts, textile, water. It has one of market slimmest form-factors with 17.5mm width, allowing for a flexible and easy installation on DIN rail, using the same space as any modular 1-pole DIN device. It also offers a sealable cover, simple and precise settings with screw trimmers. It provides automatic shutdown management and fault information to user for a quick fault identification and troubleshooting. multi function controller for wide choice selected in hard-wired logic automated systems, ideal for refurbishment of old installations without using a PLC. 0 0 0 0 0 0 0 0 0 0 0 0

Specification

Type of electric connection	Screw connection
Single-phase over voltage possible	TRUE
Three-phase over voltage possible	FALSE
Single-phase under voltage possible	TRUE
Three-phase under voltage possible	FALSE
Contains function DC-under voltage	FALSE
Contains function DC-over voltage	TRUE
Height	90 Millimetre
Single-phase hysteresis possible	FALSE
Max. permitted delay-on energization time	10 Second
Three-phase hysteresis possible	FALSE
Width	17.5 Millimetre
Contains function DC-voltage hysteresis	TRUE
Type of voltage measuring range	AC/DC
Depth	72 Millimetre
Number of contacts as normally open contact	0
Number of contacts as change-over contact	1
Voltage measuring range 1	20…80 Volt
Number of contacts as normally closed contact	0
With detachable clamps	FALSE
Response value voltage	15…100 Volt
Max. permitted off-delay time	10 Second
Min. adjustable off-delay time	0.1 Second
