TESYS GV2 CIRCUIT BREAKER THERMAL MAGNETIC 4-6.3A LUGS RING TERMINALS

Download the GV2ME106 TESYS GV2 CIRCUIT BREAKER THERMAL MAGNETIC 4-6.3A LUGS RING TERMINALS SCHNEIDER ELECTRIC product datasheet, by clicking  here!

Technical Characteristic:

• Product Code : GV2ME106
• Brand : Schneider Electric
• Product Name : TESYS GV2 CIRCUIT BREAKER THERMAL MAGNETIC 4-6.3A LUGS RING TERMINALS
• Description : MOTOR CIRCUIT BREAKER GV2ME SCHNEIDER ELECTRIC - GV2ME10
• Range : TeSys Deca
• product name : TeSys GV2
• Product or component type : Motor circuit breaker
• Device short name : GV2ME
• Device application : Motor protection
• Trip unit technology : Thermal-magnetic
• Poles description : 3P
• Network type : AC
• control type : Push-button
• [In] rated current : 6.3 A
• Thermal protection adjustment range : 4…6.3 A conforming to IEC 60947-2
• Magnetic tripping current : 91 A
• [Ith] conventional free air thermal current : 6.3 A conforming to IEC 60947-2
• [Ue] rated operational voltage : 690 V AC 50/60 Hz conforming to IEC 60947-2
• [Ui] rated insulation voltage : 690 V AC 50/60 Hz conforming to IEC 60947-2
• [Uimp] rated impulse withstand voltage : 6 kV conforming to IEC 60947-2
• Power dissipation per pole : 2.5 W
• Mechanical durability : 100000 cycles
• Width : 45 mm
• Height : 89 mm
• Depth : 78.5 mm
• Product weight : 0.26 kg
• Colour : Dark grey

Schneider Electric TeSys Deca - frame 2

The new generations of TeSys Deca Motor Circuit Breakers Frame 2 offer a complete solution for almost any application. It provides short circuit protection, overload protection, motor (ON/OFF) control.

• High-class protection up to 15kW ( 11kW for GV2RT)
• Thermal-magnetic or magnetic protection
• Operation with rotary handle, extended rotary handle, push-button, or toggle
• Various Connectors: Multi-standard screws, EverLink terminal block, spring terminal, ring-type connection.
