Technical Data
- Operating voltage : 110 V AC - 240 V AC
- Frequency : 50 - 60 Hz
- Installation height : 2 - 6 m
- Installation type : Ceiling installation, Indoor
- Colour : White
- Power consumption : ~0.5 W
- Light measurement : Mixed light measurement
- Setting range brightness : 5 - 1000 lx
- Light switch-off delay : 30 s - 30 min
- Lamp types : Incandescent/halogen lamps, fluorescent lamps, Energy saving lamps, LEDs
- Incandescent/halogen lamp load : 2000 W
- Fluorescent lamp load (conventional) not corrected : 2000 VA
- Fluorescent lamp load (conventional) parallel-corrected : 1300 VA 140 µF
- Fluorescent lamp load (conventional) series-corrected : 2000 VA
- Fluorescent lamp load (electronic ballast) : 1200 W
- LED lamp < 2 W : 55 W
- LED lamp 2-8 W : 600 W
- LED lamp > 8 W : 600 W
- Switching output : Light
- Detection range : 50 m² (ø 8 m | 360°)
- Detection angle : 360°
- Ambient temperature : -20°C ... 50°C
- Type of protection : IP 55 (Sensor), IP 20 (power module
Function description
- Passive infra-red motion detector for ceiling installation in false ceilings
- Circular detection area 360°, up to Ø 8 m (50 m2) at mounting height 2.5 m
- 1 channel light (Relay, 230 V)
- Automatic motion and brightness-dependent control for lighting
- Mixed light measurement suitable for fluorescent lamps (FL/PL/ESL), halogen/incandescent lamps and LEDs
- Operation as fully automatic device
- Brightness switching value configurable, teach-in function
- Pulse function for staircase light time switch
- Time delay configurable
- Extension of detection area via Master/Slave switching
