AUXILIARY CONTACT ALARM SD AC DC CCC / G

Download the A9N26927 AUXILIARY CONTACT ALARM SD AC DC CCC / G SCHNEIDER ELECTRIC product datasheet, by clicking  here!

Function of the Miniature Circuit Breaker (MCB):

• Product Code : A9N26927
• Brand : Schneider Electric
• Product Name : AUXILIARY CONTACT ALARM SD AC DC CCC / G
• Description : ACCESSORIES MCB C120, DPN, C60, SW60-DC SCHNEIDER ELECTRIC - A9N26927
• range of product : Acti9
• Product or component type : Fault contact
• Device short name : SD
• Signal contacts composition : 1 C/O
• Mounting mode : Fixed
• Mounting support : DIN rail
• Comb busbar and distribution block compatibility : Top: YES
• Height : 85.3 mm
• Width : 9 mm
• Depth : 73.5 mm
• Net weight : 30 g
• Colour : White
• Warranty (in months) : 18

Schneider Acti9 VOLTAGE RELEASE MNX for MCBs & RCDs

Designed with protection and a wide range of features, the Acti9 tripping management and DIN rail tripping system combines easy installation with high functionality. Includes: automatic recovery, remote control, remote indication, and tripping. VisiTrip for rapid detection of faulty insulators and reduced intervention time. Clip-on assembly system for ease of use. It is used to enhance protection in commercial and industrial buildings, while addressing tripped circuits caused by: short circuits, overcurrents, ground leakage currents, voltage drops, and manual safety tripping.

You can shop safely at ListrikKita.com because all the goods we sell are guaranteed to be 100% genuine, have an official guarantee, and can be accompanied by a letter of authenticity. To get the best MCB prices and further information, please contact our sales or marketing team by clicking here. Happy shopping.

This Acti9 SD electric auxiliary is a remote fault indicator contact. It is dedicated to Acti9 C120, C60H-DC, DPN N Vigi. It comes with 1 changeover contact indicating the position of the associated device. It indicates the position of the associated device in the event of electrical fault or action on the tripping auxiliary. The width in 9mm pitches is 1. The Ue rated operational voltage is 24VAC to 415VAC or 24VDC to 130VDC. The operating frequency is 50Hz or 60Hz. The Ie rated operational current is 6A under 24VDC, 2A under 48VDC, 1.5A under 60VDC, 1A under 130VDC. The Ie rated operational current is 6A under 24VAC to 240VAC, 3A under 415VAC. There is a mechanical state indicator and a test function button on the front face. Be careful, this device is not compatible with an ID residual current circuit breaker. The operating temperature is -25°C to + 50°C. The storage temperature is -40°C to + 85°C. This product complies with IEC/EN 60947-5-1 standard and EN 62019-2 standard only for C120.

Specification

Number of contacts as normally open contact	0
Suitable for max. current main contact unit	125 Ampere
Number of contacts as change-over contact	1
Rated voltage	240 Volt
Rated switch current	6 Ampere
Number of contacts as normally closed contact	0
With auto test for earth leakage function	FALSE
Width in number of modular spacings	0.5
Device fitting	Miniature circuit breaker (MCB)
Suitable for max. number of poles main contact unit (total)	4
Number of fault-signal switches	1

Documents

• Declaration of conformity - EU_doc_Auxiliaries_contact
• Brochure - Acti9 auxiliaries brochure
• Circularity Profile - Acti9 - Auxiliary Contact - iOF 1OC 100mA-6A - Product End of Life Instructions
