ADVANCED CONTROL UNIT LUCB CLASS 10 4.5-18A 24VDC
| Kode Produk | LUCB18BL |
| Nama Produk | ADVANCED CONTROL UNIT LUCB CLASS 10 4.5-18A 24VDC |
| Keterangan | POWER BASE TESYS U SCHNEIDER ELECTRIC - LUCB18BL |
| Brand | Schneider Electric |
| Ketersediaan Stok |
|
|
TeSys U control and diagnostic unit to be inserted in advanced power bases LUB320, LUB380, LUB380 to form a TeSys U starter controller, for 3-phase motor applications up to 7.5kW@400V. It provides full protection to motors with a rated current Ir 4.5-18A (Ir adjustable), overload tripping class 10, short circuit at 13 x Irmax, overcurrent at 14.2 x Ir, phase loss, insulation fault (protection of equipment only). It provides a thermal overload alarm to be used locally using a LUFDA module or remotely using a LULC module, and a test push button for overload simulation. To be used with a 24V DC voltage for the control of the starter (through the control terminals A1/A2 located in the power base). Certified when used in conjunction with a LUB power base (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh). Range: TeSys Product specific application: Basic protection and advanced functions, communication Data sheets: https://www.se.com/id/id/product/download-pdf/LUCB18BL?filename=Schneider+Electric_TeSys-Ultra_LUCB18BL.pdf Instruction sheets: https://download.schneider-electric.com/files?p_enDocType=Instruction+sheet&p_File_Name=162998401A05-17.pdf&p_Doc_Ref=1629984 |
|
