You must have seen industrial robots that can move quickly and accurately, right? Did you know that there is an electrical device that plays an important role in the smooth, stable, precise, and agile movement of the robot? This electrical device is called a servo motor!

The servo motor itself is an electric motor designed to control position, speed, and torque very accurately continuously. This tool has become an important device in various modern industries, such as automation and robotics.

Want to know more about servo motors and what their functions are? Read this article until the end!

What is a Servo Motor?

A servo motor is an electrical device that is commonly used in smart industrial machines. Its function is to push or rotate objects with high-precision control in terms of angular position, acceleration, and speed. This is a capability that ordinary motors do not have.

If you want an industrial machine that can rotate and move objects at certain angles or distances, you must use this Servo Motor device. This can also be possible with a combination of a regular motor and additional sensors, in this case an encoder for position feedback.

In a servo motor device, there is a controller called a servo drive. This part is the most important and sophisticated part of the servo motor, because it is designed for high precision. In addition, this controller also acts as an intermediary between the motor and the digital control element, because it can change the signal according to needs.

This device is the right choice for precision or accuracy in machines to be the main thing in industrial machines. The level of accuracy/tolerance (high precision positioning) of the servo motor is the main indicator of the specification.

However, not all applications can use servo motors individually. For example, in factory machine processes such as CNC, servo motors must be used more than 1 unit on one machine so that a PLC such as Modicon M262 is needed to give commands synchronously to all servo motors used.

Then, the communication protocol used must also be an open protocol to allow PLCs and servo motors from different vendors to work.

Components and Functions of Servo Motors

There are dozens of components that make up a servo motor, and each component has an important role in the functionality of the device. The following are the most important servo meter components with significant roles:

1. Stator: This component creates a rotating magnetic field to generate torque efficiently.

2. Coil: The current flowing in this coil will produce a rotating magnetic field.

3. Shaft: The shaft component functions to channel the motor's output power, where this load is driven through a transfer mechanism.

4. Encoder: The optical encoder always observes and counts the number of rotations completed and monitors the position of the shaft.

Then, in terms of its function, this servo motor has a function to convert the control signal into the angular displacement of the motor's output shaft or angular velocity. Then, the feedback system in this electronic component is useful for providing information on the motor's rotation position.

The servo motor also functions to receive control signals from external sources and generate signals that are useful for driving the motor. Other functions are to move joints, regulate car speed, move and pull the interior of commercial aircraft, adjust the position of radio-controlled aircraft control surfaces, and even drive electrically operated machines.

So that your industrial operations can run well and efficiently, use a servo motor from a manufacturer that has proven product quality. Also make sure you choose a product that suits your application needs!
