RELAY THERMAL BEBAN LEBIH 17-25A
| Pilih Tipe |
|
||||||||||||||||||||||
| Pilih Arus pengenal |
|
||||||||||||||||||||||
| Kode Produk | LRD325 | ||||||||||||||||||||||
| Nama Produk | RELAY THERMAL BEBAN LEBIH 17-25A | ||||||||||||||||||||||
| Keterangan | TESYS D SCHNEIDER ELECTRIC - LRD325 | ||||||||||||||||||||||
| Brand | Schneider Electric | ||||||||||||||||||||||
| Arus Pengenal | 17-25A | ||||||||||||||||||||||
| Tipe | TeSys D | ||||||||||||||||||||||
| Ketersediaan Stok |
|
||||||||||||||||||||||
|
Kode Produk : LRD325
Brand : Schneider Electric
Nama Produk : RELAY THERMAL BEBAN LEBIH 17-25A
Keterangan : TESYS D SCHNEIDER ELECTRIC - LRD325
TeSys LRD thermal overload relay, 25A/690V, thermal setting range 17-25A, tripping class 10A, for protection of 3-phase motors 11kW@400V. Differential device with phase failure (loss). It provides a thermal adjustement dial, a manual-automatic reset selector, a test selector for simulation of a tripping, reset and stop buttons, a flag indicator and 2 auxiliary contacts 1NO+1NC for fault signalling. Settings are protected by a transparent cover lockable by sealing. Connection by EverLink BTR screw terminals , it connects directly to the bottom terminals of 3-pole contactors LC1D40A-D80A. Mounting on DIN rail or screw fixing, separated from the contactor, with use of a terminal block LAD96560 (to be ordered separately). Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHs/Reach). Specification
Documents
|
|||||||||||||||||||||||
