MCB 3P 6A 25kA KURVA C

Miniature Circuit Breaker (MCB) adalah sebuah perangkat elektromekanikal yang dapat melindungi rangkaian listrik dari arus yang berlebihan dengan cara memutuskan arus tersebut secara otomatis saat melewati batas tertentu. Miniature Circuit Breaker (MCB) berfungsi sebagai pemutus arus, pengaman hubungan arus pendek atau korsleting, sakelar utama dan pengaman untuk beban berlebihan. Miniature Circuit Breaker (MCB) Listrik bekerja secara otomatis memutus arus listrik ketika arus yang melewatinya melebihi arus nominal pada Schneider Miniature Circuit Breaker (MCB) tersebut.

Fungsi Miniature Circuit Breaker (MCB) :

• Mengamankan kabel terhadap beban lebih dan arus hubung singkat
• Melakukan arus tanpa pemanasan lebih
• Membuka dan menutup sebuah sirkuit di bawah arus pengenal
• Pengaman terhadap kerusakan isolator

Pemilihan Pemutus Tenaga Miniature Circuit Breaker (MCB)

Pemilihan pemutus tenaga ditentukan oleh beberapa hal :

• Standar
• Kapasitas Pemutusan
• Arus Pengenal
• Tegangan
• Jumlah Kutub
• Bentuk Kurva Trip
• Frekuensi system, dan
• Aplikasi Beban

Untuk unduh datasheet produk, silakan klik disini!

ListrikKita.com menjual beberapa brand yaitu, Schneider Electric, ABB, Siemens, Fuji Electric, LS Electric, Nidec, Socomec, L&T, Ducati Energia, Chint, Hager, Nader, Axle, Lifasa, Himel, APC, Hensel, Philips, GE Current, Simon, Hannochs, Nusa, Gesits, U-Winfly, Hioki, TAC, Imou, Airquality, Legrand, Mennekes, Epcos, Safe-D-Lock, Leroy Somer, Allen-Bradley, Sunfree, Secure, Telergon, Circutor, OPT, CIC, PM, Supreme, Kabelindo, Kabelmetal Indonesia, Alpha, Selis, Telemecanique, Trafindo, Esitas, BOSS, B&D Transformer, Asco, Secure, Howig, Onesto, Veloce dan masih banyak lagi.

Anda dapat berbelanja dengan aman di ListrikKita.com karena semua barang yang kami jual dijamin 100% asli, bergaransi resmi dan dapat disertai dengan surat keaslian barang. Untuk dapatkan harga MCB terbaik dan informasi lebih lanjut bisa menghubungi tim sales atau marketing kami silakan klik disini. Selamat berbelanja

This Acti9 iC60L is a low voltage miniature circuit breaker (MCB). It has 3P with 3 protected poles, rated current 6A and C tripping curve. The rated short circuit breaking capacity goes up to 50kA at 220VAC to 240VAC conforming to EN/IEC 60947-2 standard and 15000A at 400VAC conforming to EN/IEC 60898-1 standard. It complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. This miniature circuit breaker is for protection against short circuit and overload current in all applications. Its unique VisiTrip indicator reduces intervention time by showing the faulty circuit. Its VisiSafe green strip guarantees the physical opening of the contacts to allow downstream maintenance. Its fast closing mechanism independent of manual operation improves its service life. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ui rated insulation voltage is 500VAC. Its limitation class 3 (according to EN/IEC60898-1) improves downstream circuit protection cost. It is DIN rail mountable. Its width is 6 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is white (RAL9003). The dimensions are (W) 54mm x (H) 85mm x (D) 78.5mm. The weight is 0.375kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -35°C to 70°C. The storage temperature is -40°C to 85°C.

Specification

Built-in depth	44.5 Millimetre
Frequency	50…60 Hertz
Width in number of modular spacings	3
Number of poles (total)	3
Rated insulation voltage Ui	500 Volt
Number of protected poles	3
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	15 kiloampere
Additional equipment possible	TRUE
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	50 kiloampere
Rated impulse withstand voltage Uimp	6 Kilovolt
Degree of protection (IP)	IP20
Rated current	6 Ampere
Rated voltage	400 Volt
Release characteristic	C
Concurrently switching neutral conductor	FALSE
Voltage type	AC/DC
Flush-mounted installation	FALSE
Explosion-proof	FALSE
Connectable conductor cross section solid-core	1…25 Square millimetre
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	25 kiloampere
Over voltage category	4
Ambient temperature during operating	-35…70 Degrees celsius
Current limiting class	3
Connectable conductor cross section multi-wired	1…16 Square millimetre
Pollution degree	3
Power loss	1.3 Watt
