MCB 1P 40A 25kA CURVA C

Download the 2CCS881001R0404 MCB 1P 40A 25kA CURVA C datasheet, by clicking here!

Technical Characteristic:

• Product Code : 2CCS881001R0404
• Brand : ABB
• Product Name :MCB 1P 40A 25kA CURVA C
• Description : MCB S 801 C-C40 254VAC/125VDC ABB - 2CCS881001R0404
• Number of Protected Poles: 1
• Number of Poles: 1P
• Release Type: C
• Input Voltage Type: AC/DC
• Rated Current : 40 A
• Width: 27 mm
• Length: 82.5 mm
• Depth: 82.5 mm
• Height: 95 mm
• Weight: 245 gr
• Standards: IEC/EN 60947-2

ABB High Performance Circuit Breakers HPCBs - S800

The S801C-C40 is a 1-pole High Performance Circuit breaker with C-characteristic, with cage terminal and a rated current of 40 A. It is a current limiting device with a maximum breaking capacity of 25kA at 240/415V. It can be used for voltages up to 254/440V and in DC as well. It has two different tripping mechanisms, the thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. The S801C-C40 complies with IEC/EN 60898-1 and IEC/EN 60947-2 and allows the use for residential, commercial and industrial applications. It has numerous of approvals, therefore it can be used worldwide. The extensive range of accessory makes the use of S801C-C40 more comfortable. Due to the fast arc extinction of S801C-C40 your application will be secured.
