ELECTRONIC OVER CURRENT RELAYS AUTOMATIC 5A-60A 24VAC/DC
| Pilih Arus pengenal |
|
||||||||||||||||||||||||||||||||||||||||||||||
| Pilih Tegangan coil |
|
||||||||||||||||||||||||||||||||||||||||||||||
| Kode Produk | LT4760BA | ||||||||||||||||||||||||||||||||||||||||||||||
| Nama Produk | ELECTRONIC OVER CURRENT RELAYS AUTOMATIC 5A-60A 24VAC/DC | ||||||||||||||||||||||||||||||||||||||||||||||
| Keterangan | ELEKTRONIC OVER CURRENT RELAY (EOCR) SCHNEIDER ELECTRIC - LT4760BA | ||||||||||||||||||||||||||||||||||||||||||||||
| Brand | Schneider Electric | ||||||||||||||||||||||||||||||||||||||||||||||
| Arus Pengenal | 5-60A | ||||||||||||||||||||||||||||||||||||||||||||||
| Tegangan Coil | 24V AC/CD | ||||||||||||||||||||||||||||||||||||||||||||||
| Tipe | Elektronic Over Current Relay (EOCR) | ||||||||||||||||||||||||||||||||||||||||||||||
| Ketersediaan Stok |
|
||||||||||||||||||||||||||||||||||||||||||||||
|
Kode Produk : LT4760BA
Brand : Schneider Electric
Nama Produk : ELECTRONIC OVER CURRENT RELAYS AUTOMATIC 5A-60A 24VAC/DC
Keterangan : ELEKTRONIC OVER CURRENT RELAY (EOCR) SCHNEIDER ELECTRIC - LT4760BA
TeSys LR47 electronic overcurrent relay, 60A/690V, with automatic reset, to be supplied with 24V AC/DC, for protection of motors with a rated current 5-50A. It provides 3 dials to adjust the protection, LOAD (5-60A) for the overcurrent level, O-TIME (0.3-10sec) for the acceptable duration of the overcurrent, R-TIME (1-120sec) for the automatic reset delay. In addition, the device trips when there is a missing phase during more than O-TIME. The device has a reset button, a test/stop button, 2 LED indicators (Run/Trip), 2 auxiliary contacts 1NO+1NC for fault signalling. Settings can be locked by sealing the transparent cover. DIN rail mounting, without power terminals (currents monitored by 2 current transformers crossed by the motor cables). Multi standards certified (IEC, UL, CSA, CCC, EAC), it conforms to RoHS/REACh regulation. Specification
