CONTACTOR 4P (4NO) 60A AC-1 COIL 220VAC

Name: CONTACTOR 4P (4NO) 60A AC-1 COIL 220VAC
Brand: SCHNEIDER ELECTRIC
Price: 2539404.72 IDR
Availability: InStock

Pilih Arus pengenal

60A

80A

Pilih Tegangan coil

110VAC

220VAC

24VDC

380VAC

48VAC

Kode Produk

LC1DT60AM7

Nama Produk

CONTACTOR 4P (4NO) 60A AC-1 COIL 220VAC

Keterangan

TESYS D SCHNEIDER ELECTRIC - LC1DT60AM7

Brand

Schneider Electric

Rated Current

60A

Pole Contact Composition

4NO

Control Circuit Voltage

220VAC

Tipe

TeSys D

Ketersediaan Stok

${item.title}
Stok Tersedia

Stok Tidak Tersedia
Tersedia di ${resources.length} lokasi Cabang - Lihat Semua
Tidak ada data cabang

For a video explaining the product, click here!

TeSys Deca contactor, 4 poles (4NO), for non-inductive load applications up to 60A/440V AC-1. It provides a 220V 50/60Hz AC coil, 1NO+1NC built-in auxiliary contacts (NC mirror certified), power connections by EverLink BTR screw terminals and control by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (70mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).

Specification

Type of electrical connection of main circuit	Screw connection
Width	70 Millimetre
Rated control supply voltage AC 50 Hz	220 Volt
Rated control supply voltage AC 60 Hz	220 Volt
Number of normally closed contacts as main contact	0
Number of normally open contacts as main contact	4
Number of auxiliary contacts as normally closed contact	1
Number of auxiliary contacts as normally open contact	1
Modular version	FALSE
Operating voltage AC 50 Hz	440 Volt
Depth	120 Millimetre
Operating voltage AC 60 Hz	440 Volt
Rated operation current Ie at AC-1, 400 V	60 Ampere
Height	122 Millimetre
Voltage type for actuating	AC
