AUXILIARY CONTACT 1 OC OR 1 SD OR 1 SDE OR 1 SDV LOW LEVEL

It is a single low-level auxiliary contact that provides all the different indications remotely for Compact NSX, Compact NS, PowerPact Multistandard and EasyPact CVS circuit breakers. Remote status information are ON/OFF (OF), trip indication (SD) and fault-trip indication (SDE) for all circuit breakers types. The remote status information for trip indication due to an earth fault (SDV) is used for Compact NSX and PowerPact Multistandard. The contacts are installed in the device in dedicated slots. This auxiliary contact is a common point changeover type contact with 1 normally open contact and 1 normally closed contact. The rated current is 5A and the minimum load is 1MA at 4 VDC for utilization categories AC12/AC15/DC12/DC14. One device embeds 5 auxiliaries contact type. It complies with IEC 60947-5-1 standard.

Specification

Documents

• Declaration of conformity - UK-DoC_OF-SD-SDE-SDV_screw_NSX-NS-INS_AUX_PB20111301-UK
• Environmental Disclosure - standard auxiliary contact, circuit breaker status OF/SD/SDE/SDV, 1 changeover contact type, screwless spring terminals - Product Environmental Profile
• Instruction sheet - Auxiliary Signalling Contact - Instruction Sheet
• User guide - ComPacT NS - Circuit Breakers and Switch-Disconnectors from 630 to 3200 A - User Guide
• How to video - ComPacT NSX100/160/250 - How to Install Auxiliaries
• Catalog - EasyPact EZC Catalog
